RO Control Panel MIMIC-SILVER (1000LPH):

Technical Specification:

SALIENT FEATURES

• ✔ Micro Controller & SMPS based RO DIGITAL CONTROL Panel
• ✔ DISPLAY-Only Mimic LEDS’s
• ✔ Range: 1000LPH (1:1)
• ✔ AUTO AMPEARE Settings for RWP & HPP
• ✔ AUTO / MANUAL Mode options.
• ✔ RWT & TWT Level Sensors Provision
• ✔ HPS Provision & Monitoring
• ✔ LPS Provision & Monitoring
• ✔ HIGH & LOW Voltage Protections
• ✔ RWP & HPP Overload Protections
• ✔ UV & DOSING PUMP Connections Provision
• ✔ FLUSHING SOLENOID VALVE Connection Provision
• ✔ MIMIC Diagrammed with LED’s
• ✔ Water level sensors RWT – 2 no’s, TWT – 3 no’s



*NOTE: WATER LEVEL SENSORS RWT – 2 NO’S, TWT – 3 NO’S & SIDE CLAMPS PROVIDED ALONG WITH THIS PANELS.
